Extract Subtitles From Dvd Ubuntu

Extract SRT subtitles from DVD movies Press the right-bottom red 'Convert' and start ripping DVD subtitles to SRT file. When the SRT extracting process is finished, click 'Open output folder' to locate the generated files, you will get all the subtitles in English, Italian, Spanish. Which is exactly the same as in your original disc. A software that can be used to extract subtitles from a DVD Categories: Main Categories: DVD/SVCD/VCD (MPEG-1/2), Subtitles Sub Categories: Subtitle- Subtitle Ripping.

Subtitles, always displayed on the bottom of the screen, are aiming to help us to better understand the movie, especially when we're watching a foreign movie. There are some occassions that you want to remove subtitles from the movie or video, for example, the movie subtitle is your mother language or you can perfectly understand it and you don't want it to appear on the screen. Fortunately, there is an easy way to strip out subtitles from MKV, MP4, MOV, AVI, etc. movies or videos. Read on for details.

First of all, you need to know that subtitles are categorized into two kinds: Hardcoded subtitles and soft subtitles. Let's first figure out the difference between Hardcoded subtitles and soft subtitles.

Difference Between Hardcoded Subtitles and Soft Subtitles

Hardcoded subtitles: (also forced/embedded subtitles): Already embedded in the movies and the user cannot use tools to remove this option. These subtitles are irremovable and cannot be changed or removed altogether in theory. But there is a way to remove hardcoded subtitles from MP4 (MKV, AVI, etc.) movie video, discussed later in this tutorial.

Soft subtitles: This type of movie subtitles is not embedded in video images. It is an independent stream and can be easily turned off/on. Viewers can also freely select subtitles based on their needs if there are multiple language subtitles tracks in the (MP4) movie video. Soft subtitles are mainly used on DVD/Blu-ray.

Besides, movie subtitles can be classified into internal and external subtitles. Internal subtitles are embedded in a file container along with video and audio streams, while external subtitles are separate files that are easier to edit and change. You can refer to how to add external subtitles to MKV to learn more.

Best Tool to Remove Subtitles from a Movie or Video

To get rid of subtitles from a video or movie, EaseFab Video Converter is a great helper. It is available for Windows and Mac users both. This professional yet easy-to-use subtitle remover allows you to strip out both soft and hardcoded subtitles from MP4, MKV, AVI, MOV, FLV, etc or any other vidoe files without any quality loss. Besides removing subtitles from a movie, this tool also facilitates high-quality video editing including the crop, cut, adding external subtitle, and other more wonderful functions.

PS: Below we will take an MKV (which has soft subtitles) and an MP4 movie (which has hardcoded subtitles) as example to show you how to remove soft subtitles and hardcoded subtitles from MP4/MKV/AVI/MOV movie.

Part 1: How to Remove Soft Subtitles from an MKV Video

Screenshot of the original MKV video with soft subtitles displayed in VLC Media Player:

Step 1. Import MKV Videos

Download, install and launch EaseFab Video Converter and then import the MKV file to the program by directly dragging or clicking 'Add Video' button to locate and load the MKV file.

Step 2. Select No Subtitle Option from 'Subtitle' List

After loading MKV files, the program can automatically detect subtitles from source MKV files and list them in each video title for you to choose from. To remove soft subtitles from your movie, check 'No Subtitle' from the drop-down list.

Step 3. Select an output format and start removing subtitles from the movie.

Click 'Profile' and select MKV or other video format you want as the output. And then hit right-bottom Convert button and the program will start removing soft subtitles from the MKV video.


From

Screenshot of the soft-subtitle-removed MKV video displayed in VLC:

Part 2: How to Remove Hardcoded Subtitles from an MP4 Video

As mentioned above, the hardcoded subtitles normally cannot be removed or turned off for the subtitles are irrevocably built in video, as a part of the video images. To remove hardcoded subtitles from the movie or video, you can use EaseFab Video Converter's crop function to edit and crop the video part where subtitle is placed and then save the new video. The process of editing videos is super fast and involves a few simple steps.


Screenshot of the original MP4 video with hardcoded subtitles displayed in VLC Media Player:

Step 1. Import the MP4 Videos

Click 'Add Video' button to import the MP4 video having hardcoded subtitles.

Step 2. Crop video part with the subtitle.

Highlight the video, and then click the button of 'Edit' to enter Video Editor window. Switch to 'Crop' tab, and then simply move your mouse cursor to drag and adjust the green frame to desired position where there is no subtitles and you can preview the effect in the right player window. After that, check Apply to all and click OK to confirm the changes.

Step 3. Convert to save changes.

Click 'Profile' and select MP4 or other video format you want as the output. And then hit right-bottom Convert button and the program will start removing hardcoded subtitles from the MP4 video.


Screenshot of the hardcoded-subtitle-removed MP4 video displayed in VLC:

Related Knowledge:

Subtitle (captioning): Subtitles are derived from either a transcript or screenplay of the dialog or commentary in films, television programs, video games, and the like, usually displayed at the bottom of the screen, but can also be at the top of the screen if there is already text at the bottom of the screen...

Extract Subtitles From Dvd Ubuntu Download

> Resource > Video Tips > How to Remove Hardcoded/Soft Subtitles from a Video or Movie

Software name : Avidemux
Software version : 2.4

If you want to extract subtitle files from a DVD you should understand a little how they work. Subtitles in DVDs are contained in VOBfiles along with the main video and audio streams. We can call them all streams here to account for the difference between a self contained file and a stream. Several streams can be included in a file.

The subtitles you see on a DVD are streams of images files which appear one after the other. Each stream displays a different language. When we extract these streams of subtitles the most handy format we can save them as is actually a text file which has the timecode of when the text appears. If the subtitle file you have is in text rather than image format it makes it easier to edit it and translate it. You can easily send that file via the internet or put it on a website for others to download.

In order to create a text-basedsubtitlefile we first need to extract the images files from the DVD to two files:

  1. an *.idx file which has the time code of the image subtitles (this is called a VobSub file)
  2. and a *.sub file and contains the image information.

We can then convert those files into a single text based subtitle file. There are many different formats but Avidemux uses a very compatible one with the '.srt' extention.

note : Screenshots in the following explanation are a combination of Ubuntu (Linux) and Windows operating systems. Avidemux works well in both and the interface looks the same except for a few color differences.

Extracting to an idx / VobSub file

From the Tools menu select 'VOB' and then 'VobSub'


Then you should see the following screen asking you to Browse for three things.

  1. VOB file(s)
  2. IFO file
  3. VobSub file

Finding the VOB Files

When you click on the first Browse button in the above image we are asked to browse for the VOB files :

However sometimes it's not that clear where they are. The files we want are in a folder on the DVD (if you are doing this for files on a DVD) called VIDEO_TS folder.

Normally for a short film there is only one VOB file with video data in it. For longer films there is normally more than one, because there is a maximum file size for the VOB files.

Let's have a look at a complicated DVD structure. There are some small entries in the structure which are system files and files for the menu - we should ignore these. The files with the video, audio and subtitle files we need are the big ones. They start with names like VTS_02_1.VOB,VTS_02_2.VOB, VTS_02_3.VOB, VTS_02_4.VOB. If you click 'Browse' next to 'VOB Files' then you should browse to the appropriate directory ('VIDEO_TS') and you should see something like this :

For this task we need to select the first big VOB which in this case is VTS_02_1.VOB. The ones following it will be selected automatically. When you have selected the right one click on 'open' :

Locating the IFO file

If you click on the second button :

you will be asked to look for the IFO file. The IFO file has information on what language the different subtitle streams are, so we need to browse to find this file. If there is more that one IFO file in the DVD we need find the one that has the same beginning as the large VOB files. In this case it is VTS_02_0.IFO

When you have found it click on 'open' :

Select where to save the VobSub files

The third button :

will ask you to browse for a place to save the VobSub file. When you have found the right directory write the name of it in the box next to 'Name:' and make sure it ends with '.idx'. The below is an example (you can use any name, 'subs' is just my example) :

When you have done this, and if the other three boxes are complete, then press 'Save' :

Saving your files

When you have found or selected all the files. Then click 'OK' to shut the small window with the small buttons :

Extract Subtitles From Dvd Ubuntu Usb

and you'll get a window telling you how long the process will take.

When this process is complete you will have created a new .idx file and and new .sub file. These will be saved in the directory you choose for saving the .idx file. In my case I saved them to the desktop :

Making the '.srt' File

Now we want to merge the idx file and the .sub file into a '.srt' file. Click on the top menu 'Tools' and then 'OCR (VobSub -> Srt)':

You should see a window titled 'MiniOCR'.

Click on the 'Open' button under 'VobSub'. You will then see a window called 'VobSub Settings'.

Ubuntu

Click on 'Select .idx' and browse for and select the idx file you created in the 'Extracting to an idx / VobSub file' section.

Click on 'Open' when you have selected the idx file. You should return to the 'VobSub Settings' window :

If the DVD you are using has more than one language it should be displayed in the 'Select Language' drop down box. Select the language you want to create a subtitle file for.

Extract Subtitles From Dvd Ubuntu Media Player

When you have the right language selected click 'OK', and you should return to the 'MiniOCR' window. Now you need to select a place on your computer to save the target *.srt file to. Click on the 'Save' button in the 'Output srt' section :

You will see a window asking you to choose a folder to save the srt file in.

'

Browse until you find the right place. When you have, give the file a name by typing in a name in the box at the top

make sure the name ends in '.srt' and then click 'Save'

Now you have set your input and output files you can start the process of converting the images file in to a text file. This process is called OCR. Click 'Start OCR'.

You should see a window like this:

The OCR (Optical Character Recognition) process needs you to tell it what the characters (letters and numbers + symbols) in the subtitles are. It will display a character from the image subtitle and you have to then tell the application what the corresponding text character is. Avidemux will show you a phrase and one character for that phrase like this:

Now you must type the right character in the empty text field.

You do this because it is more accurate for you to specific exactly what the characters are than for the application to guess.

Where it says 'Current Glyph Text:' and shows an image of a character you need to enter that character using the keyboard in the box below and then click 'OK'. It does make a difference if it is a capital letter or a lower case letter. Also this process is very unforgiving at the moment. There is no undo option, so don't get it wrong!­

Sometimes 2 characters well be selected. You should enter those two characters and click enter. This may seem to be taking a long time but when you have entered all the characters and numbers the program should fly through the subtitles. You should be able to process a 90 minute film in 5 -10 minutes.

When you are finished the '.srt' file you saved will have the right ­timecode and subtitle information in it. You can open it with a text editor and it should look something like this:
